FRESH PLR TURBO 540CI STAGE 3 481X PACKAGE WITH INJECTORS AND TUNES

Up for sale is a Fresh PLR Turbo 540ci Stage 3 481X. It is in the process of being freshened at Pro Line. More pictures coming soon! This setup would be ideal for classes like: No Time, PDRA Pro Street, 10.5, LDR, No Prep etc.

Best ET's: High 3.60's @ 214mph in NT Trim, and 3.98 @ 196mph in LDR Trim (3300lbs)

Engine Specifications:

  • Block: AJPE
  • Crank: Bryant Billet Center Counterweight (Used, Mag'd Good)
  • Rods: GRP Billet Aluminum (New)
  • Pistons: Diamond (3 New)
  • Pins: Trend TP1 (Used)
  • Rings: Total Seal (New)
  • Oil Pan: Moroso (New)
  • Oil Pump: System One Billet Wet Sump (New)
  • Cam: Crane Tool Steel PLR Grind
  • Lifters: Jesel Dog Bone
  • Push rods: Smith Bros
  • Rockers: T&D Steel w/ AJPE Steel Stands
  • Heads: AJPE Stage 3 481X
  • Valves: Victory 1 Titanium
  • Locators: Victory 1
  • Springs: PAC
  • Retainers: Victory 1
  • Locks: Victory 1
  • Lash caps: Victory 1
  • Intake: Hogan's Sheet Metal with Billet Runners
  • Injectors: BA3 700 lb/hr (Fresh)
  • Valve Covers: Moroso / PLR Billet Aluminum
  • Also Includes: Tune ups from the engine in LDR Trim

Please call Eric Dillard at 770-231-2993 or Danny Coogle at 770-481-8000 or email us if you are interested or have any questions.
