$ 374.99 $ 399.99
The TurboWerx Exa-Pump is the ultimate achievement in high-temperature, high-reliability pump technology. This pump was designed from the ground up to handle the most extreme conditions found in any motor vehicle, with a special emphasis on turbocharger oil scavenging applications. Built on extremely rugged spur gear technology, there is simply no other pump that can be compared to this hi-temp, 10,000 hour continuously rated pump. Aerospace/military-grade quality and available at an affordable price.
$ 374.99 $ 399.99
Created from the exact same materials with same engineering/manufacturing and as it’s big brother Exa-Pump, the Exa-Pump Mini offers the exact same high-temperature, high-reliability pump technology in a smaller form-factor more suitable to physically tighter applications such as motorcycles, quads, personal watercraft, snow machines, or any space-limited or ultra weight-critical racing application. The Mini is also the first pump in this field to offer external motor brushes for easy/inexpensive replacement. The custom heatsink allows the entire motor/pump head assembly infinite rotation allowing optimal orientation of the in/out ports, including port functional reversal. This pump was designed from the ground up to handle the most extreme conditions found in any motor vehicle, with a special emphasis on turbocharger oil scavenging applications. Built on extremely rugged spur gear technology, this small-frame 350°F continuously rated pump offers aerospace/military-grade quality in a compact/lightweight package.
Proven, powerful, and quiet. This custom engineered pump is designed to scavenge hot turbocharger drain oil from anywhere to anywhere in automotive applications. Time-tested, proven reliability over years, and with its 1.75GPM (105GPH) scavenging capacity, it is powerful enough to scavenge oil from two turbos. It will self-prime/draw from over 5 vertical feet, and pump the oil as high as 20 vertical feet. The Exa-Pump-inspired custom black anodized finned heatsink lowers operating temperature, further enhancing reliability.
Whether the application moves 1 oz of oil a minute or up to 1.75 gallons a minute, 'under-flow' applications are no problem. In fact, the TurboWerx pump may be run dry indefinitely. May be operated up to 60PSI pressure.
Same style/performance heatsink as Exa-Pump!
This pump will fit inside a 7.25" x 4.0" x 4.0" box. It weighs less than 5 pounds, and includes anti-vibration mounting hardware. It is specified to handle a maximum oil temperature of 300+F, and the power consumption at 12 volts is less than 3.5 amps. Pump inlet and outlet fittings are standard 3/8" NPT. Also suitable for other fluids, such as rear-end, engine coolant, and water. Not compatible with ATF.
This pump is an ideal economical solution for most turbocharger scavenge applications. For higher performance and even greater reliability, see the premium model Exa-Pump here.
TurboWerx offers a limited warranty on the parts against defects in material and workmanship. Please contact Turbowerx for any Warranty Claims directly at firstname.lastname@example.org with invoice showing date of purchase. Do not remove or replace ANY fasteners. Warranty and terms of sales. Do not exceed 60PSI operating pressure. or 300F rated temperature, or >25% rated voltage (12V), else warranty voided.
100% duty-cycle brushed motor with 2000 hr (minimum) brushes
Pumping Rate: 1.75GPM (105GPH) @ 12.8 volts.
Maximum Fluid Temperature: 300F (149C)
Current consumption: 3.5 amps maximum
Inlet/Outlet fittings: 3/8” NPT F
Dimensions: 7.0” x 4.5” x 4.0”
Weight: 5 lbs
Base-Model Manual PDF
